SD-C1 - 수평롤러식 캡핑기 Type Capping Machine
■ 특징

- 수(手)작업으로 어려운 캡핑의 한계를 극복하여 준다.
- 양축 우레탄 롤러가 돌면서 캡을 돌려준다.
- 토르크 조절은 물론이고, 캡핑타이머 기능에 의하여 자유자재로 조정이 가능하다.
- 콤팩트 형으로 좁은 공간이나 콘베어 위에서도 작업이 가능하다.


■ Features

- Complicated capping is possible by manual works.
- Biaxial urethane roller rotates together with caps.
- You can easily adjust the torque by timer.
- It is a compact type and therefore work in a small space and on the conveyor is possible.


■ Specification

- Application : Trigger Cap, Pump Cap And Roundscrew Cap.
- Operationg Speed : 20~30 Pcs/min
- Cap Diameter : 20~85㎜
- Bottle Check : Electric Photo Sensor
- Torque : 25㎏~㎝
- Air Pressure : 4~5kg/cm
- Power : 220V (Single phase) 0.2㎾
- Wight : 55㎏


SD-C2 - 수직 에어척 캡핑기 Type Capping Machine
■ 특징

- 다품종 소량생산에 적합한 캡핑기이다.
- 돌출되지 않고 일반적인 둥근 스크류캡의 캡핑에 아주 적합하다.
- 에어척 작동 방식이라 코팅된 고급캡도 손상없이 캡핑이 가능하다.


■ Features

- It is a capper appropriate of small quantity batch production.
- It is appropriate for capping of normal caps which are not projected.
- As it is an air chuck operating type, capping of premium caps is possible without damages.


■ Specification

- Application : Round Screw Cap.
- Operationg Speed : 20~30 Pcs/min
- Cap Diameter : 10~80㎜
- Torque : 25㎏~㎝
- Air Pressure : 3~4kg/cm
- Power : 220V (Single phase) 0.2㎾
- Dimension : 600(L) x 700(W) x 1550(H)
- Wight : 95㎏


SD-C3A - 만능 캡핑기 Type Multipurpos Capping Machine
■ 특징

- 본 캡핑기는 나사식 원형캡 및 트리거캡, 에어펌프식캡 등 다양한 종류의 캡 및 용기모양에도 관계없이 캡핑이 가능하다.
- 특히 4축롤러가 동시에 캡을 돌려주기 때문에 확실한 캡핑이 이루어진다.
- 용기의 크기 및 높이도 조정이 간단히 이루어지며 라인 작업에 연결시켜 작업능률을 극대화 시킬 수 있다.(특허등록)


■ Features

- This capper is available for various types of caps and containers including bolt type circle caps, trigger caps and air pump type caps regardless of their shapes.
-Especially, the quad-axial roller makes the caps rotate concurrently and therefore complete capping is possible.
- You can easily adjust the size and height of the container and you can also maximize the work efficiency by connecting to line works (patent registered)


■ CE
■ Specification

- Application : Trigger Cap, Pump Cap, Roundscrew
- Bottle Size : 30Ø ~110Ø
- Cap Diameter : 25Ø ~80Ø, 특수형 30Ø ~110Ø
- Capacity : 20-30 Pcs/Min
- Torque Control : Timer Setting
- Bottle Check : Electric Photo Sensor
- Air Pressure : 4~5kg/cm
- Power : 220V (Single phase)
- Dimension : 2000(L) x 600(W) x 1650(H)


SD-C3B - 만능 캡핑기Type Multipurpos Capping Machine
■ 특징

- 본 캡핑기는 나사식 원형캡 및 트리거캡, 에어펌프식캡 등 다양한 종류의 캡 및 용기모양에도 관계없이 캡핑이 가능하다.
- 특히 4축롤러가 동시에 캡을 돌려주기 때문에 확실한 캡핑이 이루어진다.
- 용기의 크기 및 높이도 조정이 간단히 이루어지며 라인 작업에 연결시켜 작업능률을 극대화 시킬 수 있다.(특허등록)
- 기존 콘베어 위에 설치하여 사용하며, 이동이 용이한 구조이다.


■ Features

- including bolt type circle caps, trigger caps and air pump type caps regardless of their shapes.
- Especially, the quad-axial roller makes the caps rotate concurrently and therefore complete capping is possible.
- You can easily adjust the size and height of the container and you can also maximize the work efficiency by connecting to line works (patent registered)


■ CE
■ Specification

- Application : Trigger Cap, Pump Cap, Roundscrew
- Bottle Size : 30Ø ~110Ø
- Cap Diameter : 25Ø ~80Ø, 특수형 30Ø ~110Ø
- Capacity : 20-30 Pcs/Min
- Torque Control : Timer Setting
- Bottle Check : Electric Photo Sensor
- Air Pressure : 4~5kg/cm
- Power : 220V (Single phase)
- Dimension : 2000(L) x 600(W) x 1650(H)

SD-C3M Seml-Auto 만능 캡핑기 Semi-Auto Multi Capping Machine
■ 특징

- 본 캡핑기는 나사식 원형캡 및 트리거캡, 에어펌프식캡 등 다양한 종류의 캡 및 용기모양에도 관계없이 캡핑이 가능하다.
- 특히 4축롤러가 동시에 캡을 돌려주기 때문에 확실한 캡핑이 이루어진다.
- 용기의 크기 및 높이도 조정이 간단히 이루어지며 라인 작업에 연결시켜 작업능률을 극대화 시킬 수 있다.(특허등록)


■ Features

- This capper is available for various types of caps and containers including bolt type circle caps, trigger caps and air pump type caps regardless of their shapes.
-Especially, the quad-axial roller makes the caps rotate concurrently and therefore complete capping is possible.
- You can easily adjust the size and height of the container and you can also maximize the work efficiency by connecting to line works (patent registered)


■ Specification

- Application : Trigger Cap, Pump Cap, Roundscrew
- Bottle Size : 30Ø ~110Ø
- Cap Diameter : 25Ø ~80Ø, 특수형 30Ø ~110Ø
- Capacity : 20-30 Pcs/Min
- Torque Control : Timer Setting
- Bottle Check : Electric Photo Sensor
- Air Pressure : 4~5kg/cm
- Power : 220V (Single phase)
- Dimension : 2000(L) x 600(W) x 1650(H)


SD-CS - AL-CAP 씰링기 AL-CAP Sealing Machine
■ 특징

- 알루미늄 Cap을 용기에 바르게 씌우고 Bottle-Guide 중심에 밀어
  넣으면 Bottle감지 센서의 감지에 따라 Cap 씰링헤드가 회전하면서
  하강하여 알루미늄캡에 나사를 내며 캡핑한다.
- 크기나 높이에 따라 높낮이 조절도 가능하며 체엔지 파트가 간단하다.


■ Features

- Place the aluminum Cap onto the container and push it towards the center of Bottle-Guide. As the Bottle sensor detects, capping proceeds making a female screw inside while the Cap sealing head spin and descends.


■ Specification

- Application : AL-CAP, Crimping
- Bottle Size : 30⌀ ~ 110⌀이내
- Cap Diameter : 25⌀ ~ 30⌀이내
- Operating Speed : 1.5~25Pcs/min
- Air Pressure : 5 ~ 6㎏/㎠
- Power : 220V (1 Phase)
- Dimension : 650(W) x 650(L) x 1650(H)
